Genesis Matt White Square Edge Aluminium Tile Trim
£7.99
Tax included.
Shipping calculated at checkout.
Special order item: 3-5 days
Quantity
The Genesis TDP Aluminium Square Trim in Matt White is a clean, minimal profile that combines the bolder presence of a square edge with a white finish that blends naturally into light-coloured tile schemes. The 10mm square face gives it more visual weight than a straight edge trim — making it suitable as a tile edging on walls or floors, or as a decorative feature strip laid between tile rows. In matt white it sits quietly within pale and neutral schemes without the metallic contrast of a brass or silver trim. Made from AA 6063 T6 aluminium anodised to DIN 17611, with a 27mm fixing tab. Available in 10mm and 12mm depths, 2.5m lengths.
2.5m length
Sizes: 10mm, 12mm
Wall & floor use
Use as edge or feature strip
Anodised to DIN 17611
10mm square face
Material
AA 6063 T6 Aluminium
Length
2.5m
per length
Profile depth (D)
10 / 12mm
Face width
10mm
square section
Fixing tab width
27mm
Wall thickness
1mm
Finish
Matt White
anodised DIN 17611
Application
Walls & floors
Suitable for
Wall and floor tile edge finishing
Decorative feature strip between tile rows
White, cream, and light-coloured tile schemes
Ceramic, porcelain, and natural stone tiles
Internal installations
Not suitable for
Permanent outdoor exposure
Prolonged contact with alkaline materials (adhesive/grout)
Highly acidic or chemical cleaning products
Damaged finish cannot be touched up — recoating required
Square edge vs straight edge matt white — which profile do I need?
Choose square edge when
A defined, structured edge detail is wanted
The trim will also serve as a feature strip between tile rows
A more architectural finish is the goal
Choose straight edge when
The most discreet possible edge is wanted
The trim should be invisible and functional
An 8mm depth is needed
How to fit & cut aluminium tile trim
Cutting to length
1
Measure and mark the trim length required. Always measure twice before cutting.
The anodised surface is susceptible to scratching — handle carefully.
2
Cut with a fine-tooth mitre saw or metal-cutting blade.
Do not use a standard wood saw blade — use a dedicated metal or multi-material blade.
3
For external corners, mitre each piece at 45°.
On a white finish, any gap at a corner joint will be clearly visible.
4
Deburr any cut edges with a fine metal file before fitting.
Fitting the trim
1
Select the correct depth and dry-fit before applying adhesive.
2
Trowel adhesive and press the perforated fixing tab firmly into it.
3
Embed tiles flush with the top of the profile.
Remove adhesive and grout from the trim face immediately.
4
Fill the joint with grout. Wipe trim face before grout sets.
Use a matching white grout for the most seamless result.
Downloads
Technical datasheet
